TCR Palan pneumatique robuste TCR Commande à corde

  1. Technical Info
  2. TCR Palan pneumatique robuste
  3. TCR Commande à corde

TCR Line drawing

Geared Trolley Mount Dual Fall (cord control); *For informational purposes only, contact Kito for dimensional drawing

Dimension

Capacité Modèle C (in.) F a b e g h k n r t v X(ft)
1/4 TCRG250C 19 2~4 531 236 338 28 81 76 112 51 22 183 10
1/2 TCRG500C 19 2~4 531 236 338 28 81 76 112 51 22 183 10
1 TCRG1000C2 21.3 2.3~5 531 236 338 28 106 94 112 51 25 183 10
1 TCRG1000C 19.2 2.3~5 531 236 338 28 106 94 112 51 25 183 10
2 TCRG2000C2 21.9 3.3~6 630 280 338 28 127 112 132 61 32 183 10

Veuillez confirmer les spécifications avec le support technique avant l'achat.

Caractéristiques

Capacité Modèle Standard Lift (ft) Cord L (ft) Speed (ft/min @ 90 psi) Up/Down Rates (Cubic ft/min @ 90 psi) Up/Down Air Consumption Load Chain Diameter (mm) x Chain Fall Lines Net Weight (Lbs) Weight For Additional 5ft of lift (Lbs)
w/NO Load w/full Load w/NO Load w/full Load
1/4 TCRG250C 10 6 55/41 27/54 32/25 25/28 4 x 1 96 6
1/2 TCRG500C 10 6 62/43 33/53 60/49 49/57 6.3 x 1 96 6
1 TCRG1000C2 10 6 31/21 16/26 60/49 49/57 6.3 x 2 108 9
1 TCRG1000C 10 6 34/21 19/30 60/53 49/60 7.1 x 1 105 7
2 TCRG2000C2 10 6 17/10 10/15 60/53 49/60 7.1 x 2 130 10.5
