TCK Large Capacity Air Hoist
The hoist that just keeps going.
TCK Large Capacity Air Hoist
The hoist that just keeps going.
With 100% duty rating, fine-feathering controls, and reduced noise levels, there’s no question the TCK will meet all your production needs. Smooth starts and stops with variable-speed operation provide extremely accurate load positioning and control, and the high speed lifts will guarantee to improve efficiency.
Unlimited Duty Cycle
No coffee break needed – the TCK has an unlimited duty cycle built for long and demanding work shifts. You can continually operate the hoist without worrying about damage from too many starts per hour, allowing you to get the work done on your schedule.
PIPE-AWAY EXHAUST
No need to worry about oil spatter - direct your exhaust anywhere that best suits the application.
Fine Feathering Control
The spring-loaded, multi-vane motor design allows you to place and position a load exactly where you need it. Gradually control the lift with very fine feathering movements both up and down, even at low speeds.
Reduced Noise Levels
Achieve quiet operation and dampened noise levels with the external muffler. The TCK’s air-tight body contributes to its comfortable noise levels and efficient use of air. 82 dBA and below.
CAPACITY
- 3 & 6 tonnes
STANDARDS
- ASME B30.16
OPTIONS
- Plain and geared trolley mount available
- Pendant or cord control
BODY
- Resistant in even the harshest environments, high-strength cast-iron housing stands up to the toughest demands
CONTROLS
- Available with pendant or cord control
- Very fine feathering movements both up and down, even at low speeds
GEARS
- 3-step planetary gear box
CHAIN SYSTEM
- Nickel plated, corrosion-resistant chain
- Steel chain guide
HOOKS
- Forged carbon steel opens gradually without fracturing under excessive load
- Bottom and top hooks swivel 360 degrees
- Self-closing top and bottom hooks with heavy-duty hook latch
OPERATION
- Pendant and cord control
- Outstanding control for fine feathering movements using a spring-loaded multi-vane motor design
- Spring-loaded vanes maintain constant seal against cylinder wall
- Scotch-Brite muffler with threaded hole to pipe exhaust away from hoist
- Noise level: 82dBA and below
BRAKE
- Fail-safe Self-Adjusting Disc Brake
MOTOR
- Spring-loaded multi-vane
- Air supply: 60-90 psi
- 20-micron air filter or finer
- Speed control: full range variable speed control
OPERATING CONDITIONS
- -20˚C to +70˚C
Choose product configuration below to view info:
Hook Mount
Plain Trolley Mount
Geared Trolley Mount
Air Powered Trolley Mount
Click to enlarge
Click to enlarge
Dimensions
| Capacity (tonnes) | Model | Headroom C | a | b | d | e | g | h | i |
|---|---|---|---|---|---|---|---|---|---|
| 3 | TCK3000P | 21.1 | 576 | 312 | 310 | 264 | 33 | 188 | 160 |
| 6 | TCK6000P2 | 30.3 | 576 | 371 | 310 | 264 | 43 | 244 | 160 |
* All measurements in millimeters (mm) - except headroom (C-inches). Please confirm specifications with technical support before purchase.
Specifications
| Capacity (tonnes) | Model | Std. Lift (ft) | Ship Weight (lbs) | Maximum Speed - 90 PSI (ft/min) | Max Lift (ft) | Load Chain Falls | Weight per 5ft of Lift (lbs) | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Up | Down | Chain | Pendant | ||||||||
| w/Load | w/o Load | w/Load | w/o Load | ||||||||
| 3 | TCK3000P | 10 | 225 | 18 | 37 | 38 | 23 | 125 | 30 | 1 | 11.5 |
| 6 | TCK6000P2 | 10 | 295 | 9 | 18 | 19 | 12 | 62 | 30 | 2 | 23 |
Click to enlarge
Click to enlarge
Dimensions
| Capacity (tonnes) | Model | Headroom C | a | b | d | e | g | h | i |
|---|---|---|---|---|---|---|---|---|---|
| 3 | TCK3000P | 21 | 576 | 312 | 310 | 264 | 33 | 188 | 160 |
| 6 | TCK6000P2 | 30 | 576 | 371 | 310 | 264 | 43 | 244 | 160 |
. Please confirm specifications with technical support before purchase.
Specifications
| Capacity (tonnes) | Model | Std. Lift (ft) | Ship Weight (lbs) | Maximum Speed - 90 PSI (ft/min) | Max Lift (ft) | Load Chain Falls | Weight per 5ft of Lift (lbs) | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Up | Down | Chain | Pendant | ||||||||
| w/Load | w/o Load | w/Load | w/o Load | ||||||||
| 3 | TCK3000P | 10 | 223 | 18 | 37 | 38 | 23 | 125 | ---- | 1 | 11.5 |
| 6 | TCK6000P2 | 10 | 293 | 9 | 18 | 19 | 12 | 62 | ---- | 2 | 23 |
Click to enlarge
Click to enlarge
Dimensions
| Capacity (tonne) | Model | Headroom C | F | a | b | e | g | h | k | n | r | t |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3 | TCKP3000P | 21.5 | 3.3~6 | 320 | 325 | 79 | 33 | 148 | 135 | 152 | 30 | 36 |
| 6 | TCKP6000P2 | 33.4 | 6~8.6 | 447 | 480 | 104 | 43 | 185 | 170 | 195 | 89 | 70 |
* All measurements in millimeters (mm) - except headroom (C-inches). Please confirm specifications with technical support before purchase.
Specifications
| Capacity (tonnes) | Model | Std. Lift (ft) | Ship Weight (lbs) | Maximum Speed - 90 PSI (ft/min) | Max Lift (ft) | Load Chain Falls | Weight per 5ft of Lift (lbs) | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Up | Down | Chain | Pendant | ||||||||
| w/Load | w/o Load | w/Load | w/o Load | ||||||||
| 3 | TCKP3000P | 10 | 271 | 18 | 37 | 38 | 23 | 125 | 30 | 1 | 11.5 |
| 6 | TCKP6000P2 | 10 | 507 | 9 | 18 | 19 | 12 | 62 | 30 | 2 | 23 |
Click to enlarge
Click to enlarge
Dimensions
| Capacity (tonne) | Model | Headroom C | F | a | b | e | g | h | k | n | r | t |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3 | TCKP3000C | 21.5 | 3.3~6 | 320 | 325 | 79 | 33 | 148 | 135 | 152 | 30 | 36 |
| 6 | TCKP6000C2 | 33.4 | 6~8.6 | 447 | 480 | 104 | 43 | 185 | 170 | 195 | 89 | 70 |
* All measurements in millimeters (mm) - except headroom (C-inches). Please confirm specifications with technical support before purchase.
Specifications
| Capacity (tonnes) | Model | Std. Lift (ft) | Ship Weight (lbs) | Maximum Speed - 90 PSI (ft/min) | Max Lift (ft) | Load Chain Falls | Weight per 5ft of Lift (lbs) | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Up | Down | Chain | Pendant | ||||||||
| w/Load | w/o Load | w/Load | w/o Load | ||||||||
| 3 | TCKP3000C | 10 | 269 | 18 | 37 | 38 | 23 | 125 | --- | 1 | 11.5 |
| 6 | TCKP6000C2 | 10 | 505 | 9 | 18 | 19 | 12 | 62 | --- | 2 | 23 |
Click to enlarge
Click to enlarge
Dimensions
| Capacity (tonne) | Model | Headroom C | F | a | b | e | g | h | k | n | r | t | v | X(ft) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3 | TCKG3000C | 21.5 | 3.3~6 | 792 | 325 | 403 | 33 | 148 | 134 | 152 | 30 | 36 | 183 | 10 |
| 6 | TCRK6000C2 | 33.4 | 6~8.6 | 754 | 480 | 371 | 43 | 185 | 170 | 195 | 86 | 70 | 213 | 10 |
* All measurements in millimeters (mm) - except headroom (C-inches). Please confirm specifications with technical support before purchase.
Specifications
| Capacity (tonnes) | Model | Std. Lift (ft) | Ship Weight (lbs) | Maximum Speed - 90 PSI (ft/min) | Max Lift (ft) | Load Chain Falls | Weight per 5ft of Lift (lbs) | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Up | Down | Chain | Pendant | ||||||||
| w/Load | w/o Load | w/Load | w/o Load | ||||||||
| 3 | TCKG3000C | 10 | 284 | 18 | 37 | 38 | 23 | 125 | --- | 1 | 11.5 |
| 6 | TCRK6000C2 | 10 | 551 | 9 | 18 | 19 | 12 | 62 | --- | 2 | 23 |
Click to enlarge
Click to enlarge
Dimensions
| Capacity (tonne) | Model | Headroom C | F | a | b | e | g | h | k | n | r | t | v | X (ft) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3 | TCKG3000P | 21.5 | 3.3~6 | 792 | 325 | 403 | 33 | 148 | 134 | 152 | 30 | 36 | 183 | 10 |
| 6 | TCKG6000P2 | 33.4 | 6~8.6 | 754 | 480 | 371 | 43 | 185 | 170 | 196 | 86 | 70 | 213 | 10 |
* All measurements in millimeters (mm) - except headroom (C-inches). Please confirm specifications with technical support before purchase.
Specifications
| Capacity (tonnes) | Model | Std. Lift (ft) | Ship Weight (lbs) | Maximum Speed - 90 PSI (ft/min) | Max Lift (ft) | Load Chain Falls | Weight per 5ft of Lift (lbs) | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Up | Down | Chain | Pendant | ||||||||
| w/Load | w/o Load | w/Load | w/o Load | ||||||||
| 3 | TCKG3000P | 10 | 284 | 18 | 37 | 38 | 23 | 125 | 30 | 1 | 11.5 |
| 6 | TCKG6000P2 | 10 | 551 | 9 | 18 | 19 | 12 | 62 | 30 | 2 | 23 |
Click to enlarge
Click to enlarge
Dimensions
| Capacity (tonne) | Model | Headroom C | F | a | b | e | g | h | k | n | r | t |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3 | TCKM3000P | 29.5 | 3.94~6 | 595 | 442 | 266 | 33 | 125 | 127 | 140 | 35 | 43 |
| 6 | TCKM6000P2 | 34.1 | 4.92~7 | 661 | 503 | 274 | 43 | 140 | 140 | 155 | 35 | 58 |
* All measurements in millimeters (mm) - except headroom (C-inches). Please confirm specifications with technical support before purchase.
Specifications
| Capacity (tonne) | Model | Standard Lift (ft) | Pendant L (ft) | Maximum Speed - 90 PSI (ft/min) | Traversing Speed (ft/min) | Minimum Radius For Curved (mm) | Load Chain Diameter (mm) x Chain Fall Lines | Net Weight (Lbs) | Weight For Additional 5ft of lift (Lbs) | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Up | Down | |||||||||||
| w/Load | w/o Load | w/Load | w/o Load | |||||||||
| 3 | TCKM3000P | 10 | 6 | 18 | 37 | 38 | 23 | 65 | 1300 | 12.5 x 1 | 326 | 11.5 |
| 6 | TCKM6000P2 | 10 | 6 | 9 | 18 | 19 | 12 | 65 | 2000 | 12.5 x 2 | 461 | 23 |
